According to the laser structure and application scenarios, fiber laser cutting is mainly divided into the following types:

(1) Continuous Fiber Laser Cutting (CW)

• The laser output is a continuous wave, which is suitable for high-precision, high-speed cutting, such as sheet metal fabrication.
• It is mainly used for fine cutting of stainless steel, carbon steel, aluminum alloy and other materials.


(2) Pulsed Fiber Laser Cutting (QCW/Pulsed)

• The laser is output in the form of pulses and is suitable for highly reflective materials (e.g. copper, brass) or precision micromachining.
• It is often used for fine cutting and drilling in electronic components, precision instruments and other fields.


(3) Multi-mode fiber laser cutting

• It is suitable for medium and heavy plate cutting (usually < 30mm), with a wide beam pattern and uniform energy distribution.
• It is mainly used for industrial-grade sheet metal processing.


(4) Single-mode fiber laser cutting

• The beam quality is higher, the spot is smaller, and it is suitable for high-precision cutting of ultra-thin materials (<3mm).

• It is often used in the electronics industry, precision instrument manufacturing, etc.

What materials can be cut with fiber lasers?

With its high energy density, high beam quality and excellent focusing performance, fiber lasers can efficiently cut a variety of metallic and non-metallic materials, and are widely used in industrial manufacturing. The following are the main applicable material classifications and cutting characteristics:

1. Metallic materials (main application areas)

(1) Carbon steel (low carbon steel, medium carbon steel)
Applicability: ⭐️⭐️⭐️⭐️⭐️ (Best Fit)
Cutting features:

• The fiber laser has a high absorption rate of carbon steel, a fast cutting speed, and a smooth incision.

• Oxygen (O₂) is often used as an assist gas to improve cutting efficiency by oxidation reaction.
• Cutting thickness: typically 0.5mm–30mm (ultra-high power fiber laser can cut thicker).


(2) Stainless steel (304, 316, etc.)

Applicability: ⭐️⭐️⭐️⭐️⭐️
Cutting features:

• Nitrogen (N₂) is usually used when fiber laser cutting stainless steel to avoid oxidation and keep the cut silver and slag-free.

• Compared to CO₂ lasers, fiber lasers cut stainless steel faster and are especially suitable for thin sheets (<6 mm).
• Cutting thickness: usually 0.1mm–20mm.


(3) Aluminum and aluminum alloys

Applicability: ⭐️⭐️⭐️⭐️ (highly reflective material, high power required)
Cutting features:

• Aluminum has a high reflectivity to laser and requires a high-power (≥1kW) fiber laser with nitrogen or compressed air for cutting.

• Slag is easy to occur during cutting, and parameters need to be optimized (e.g., increasing air pressure, adjusting focus).

• Cuttable thickness: usually 0.5mm–15mm.

(4) Copper and copper alloy (brass, copper)

Applicability: ⭐️⭐️⭐️ (high reflection, high thermal conductivity, difficult to cut)
Cutting features:

• Copper has an extremely high laser reflectivity (>90%) and requires either a pulsed fiber laser or a high-power CW laser (≥2kW).

• Nitrogen (N₂) or compressed air is usually used to assist in cutting to avoid oxidation.
• Cutting thickness: usually 0.1mm–5mm (thicker materials require special processing).



(5) Titanium alloy

Applicability: ⭐️⭐️⭐️⭐️ (commonly used in aerospace and medical industries)
Cutting features:

• Inert gases (e.g. argon) need to be used to prevent oxidation at high temperatures.

• The incision quality is high and there are no heat-affected zone (HAZ) issues.
• Cuttable thickness: usually 0.5mm–12mm.


(6) Other metals (galvanized sheet, nickel alloy, etc.)

• Galvanized sheet: suitable for cutting, but the parameters need to be controlled to avoid volatilization of the zinc layer to contaminate the lens.

• Nickel alloys (e.g. Inconel): can be cut, but requires a high-power laser.

2. Non-metallic materials (partially applicable)

Fiber lasers are mainly optimized for metal cutting, but some non-metallic materials can also be cut, but the effect is not as good as CO2 lasers or UV lasers:

(1) Plastics (ABS, acrylic, etc.)

• Can be cut, but easy to melt, the edges may be carbonized, low power + high speed cutting is required.
• CO2 laser or UV laser processing is more recommended.

(2) Composite materials (carbon fiber, glass fiber)

• Can be cut, but the resin matrix may burn, and gas protection needs to be optimized.
• Professional composite material cutting usually uses water jet or ultrafast laser (picosecond/femtosecond).

(3) Wood, leather, cloth

• Theoretically, it can be cut, but the heat effect is large and the edges are easy to burn. CO2 laser is more suitable.

3. Materials not suitable for fiber laser cutting

• Highly reflective materials (such as gold and silver): The reflectivity is too high and the laser head is easily damaged.
• Ceramics and glass: They are easy to crack and are more suitable for ultrafast laser (picosecond/femtosecond) or water jet cutting.
• PVC and other chlorine-containing plastics: Toxic gases will be generated during cutting, so laser cutting is prohibited.

Fiber laser cutting is most suitable for metal materials, especially carbon steel, stainless steel and aluminum, but its cutting ability for highly reflective materials (such as copper) and non-metallic materials (such as plastics) is relatively limited. It is necessary to select the appropriate laser type according to specific needs.

What are the advantages of fiber laser cutting?

Fiber laser cutting has many advantages over other industrial cutting technologies. These include:

1. High energy efficiency: Photoelectric conversion efficiency reaches 30%-50%, which is much higher than CO2 laser (10%-15%), and energy consumption is lower.
2. High precision: Good beam quality (M² close to 1), small spot diameter (0.1-0.3mm), suitable for fine cutting.
3. Fast speed: Cutting thin plates is 2-3 times faster than CO2 laser (such as 1mm stainless steel can reach 30m/min).
4. Simple maintenance: No need for reflector calibration, maintenance-free optical fiber transmission, and service life of more than 100,000 hours.
5. Low cost: Low power consumption, no need to regularly replace gas laser tubes, and the comprehensive use cost is more than 30% lower.
6. Material adaptability: Especially suitable for cutting highly reflective metals (aluminum, copper) and thin medium plates.

What are the disadvantages of fiber laser cutting?

Fiber laser cutting is a widely adopted technology with a wide range of uses. Even so, fiber laser cutting machines still have some limitations for some users. These limitations include:

• Material limitations: Certain materials, such as plastics that release toxic gases, cannot be cut with fiber laser cutting machines. These materials include PVC, ABS, polycarbonate, and high-density polyethylene (HDPE).
• Maintenance and care: Fiber laser cutting machines require proper care and regular maintenance. Neglecting maintenance can cause damage to internal parts such as the focusing lens, which can significantly reduce cutting performance.
• Initial cost: While fiber laser cutting machines have low operating costs, they still require a certain initial investment to purchase the equipment. The only consumable for this type of laser is electricity.
• Material thickness: Fiber lasers can only cut materials up to a few centimeters thick. This may not be sufficient for some applications.

What are the differences between fiber laser and CO₂ laser?

The difference between fiber lasers and CO2 lasers lies in the type of laser system. Fiber lasers use a rare earth material doped fiber laser cavity to produce an amplified beam. On the other hand, CO2 lasers use a gas discharge tube to produce the laser light.

What are the applications of fiber laser cutting machines?

Fiber laser cutting machines are widely used in various industries, including:

• Automobile manufacturing: cutting of precision parts such as body sheet metal, exhaust pipes, gears, etc.
• Aerospace: processing of high-temperature resistant materials such as titanium alloy casings and aluminum alloy skins.
• Electronics and electrical appliances: cutting of microstructures such as mobile phone middle frames, PCB templates, and heat sinks.
• Metal processing: stainless steel kitchenware, metal artworks, building steel structures, etc.
• New energy: cutting of lithium battery pole pieces and solar brackets.

How to choose a fiber laser cutting machine?

The choice of fiber laser cutting machine directly affects processing efficiency, cost and product quality. The following are the key factors to consider when purchasing to help you choose the most suitable equipment:

Power Options:

1. 500W-1kW: suitable for 0.5-5mm thin plates (e.g. electronic components).
2. 2kW-6kW: mainstream industrial grade, can cut 3-20mm carbon steel/stainless steel.
3. 8kW-20kW: Thick plate cutting (>20mm) or high-speed production needs.

Processing Format:

1. Small machine (1.5m×3m): Precision parts.
2. Standard machine (2m×4m): General purpose sheet processing.
3. Customized oversized countertops: shipbuilding, construction machinery industry.

Core Configuration:

• Laser brands: IPG, Ruike, Chuangxin, etc.
• CNC system: Baichu, PA, Siemens.
• Guide rails/gears: high-precision linear guides/helical gear transmissions.



Accessibility:

• Autofocus: Adapt to different thickness materials.
• Changing workbenches: Increase continuous production efficiency.
• Dust removal system: Handling of cutting fumes (optional).

Budget & After-sales:

• Domestic equipment (100-3 million yuan): cost-effective, fast after-sales response.
• Imported equipment (300-8 million yuan): ultra-high precision, suitable for high-end manufacturing.

Summary

Fiber laser cutting is an advanced processing technology based on high-brightness fiber lasers, which generates high-energy laser beams through fiber media doped with rare earth elements, and cooperates with precisely controlled parameters such as power, speed, focus and auxiliary gas to achieve efficient precision cutting of metals and other materials. Its core advantages lie in excellent beam quality, high energy conversion efficiency and flexible processing adaptability, the main types include continuous, pulsed and ultrafast fiber laser systems, which are widely used in sheet metal fabrication in industrial manufacturing, auto parts production and other fields, and have become an indispensable key process for modern precision manufacturing.
